The Portal stays planted, rips, has the incredibly efficient 3VO suspension design and is overall a bike we would love to stay on...Simply put, this bike is up there with the best all-around trail bikes on the market today.
Available in store
CloseThe Portal stays planted, rips, has the incredibly efficient 3VO suspension design and is overall a bike we would love to stay on...Simply put, this bike is up there with the best all-around trail bikes on the market today.
| PORTAL | A2 |
|---|---|
| Frame | Triple-butted 6061 aluminum, 130mm travel 3VO suspension, Enduro¨ Max sealed bearing pivots, 1.5 – 1 1/8Ó tapered head tube, 12x148mm thru-axle, Internal dropper post routing, Custom Jamis upper chainguide mounts, ISCG05 lower chainguide mounts, Fox Float DPS Performance Series EVOL shock w/3-position compression, 10mm shock hardware, replaceable derailleur hanger |
| Fork | Fox 34 Rhythm Series Float 29″ w/ sweep adjust compression & lock-out,15x110mm axle, air spring compression, rebound adjust, tapered alloy steerer, 130mm travel, 51mm rake |
| Headset | FSA Orbit IS Integrated, 8mm cone spacer |
| Wheels | Stan’s No Tubes Flow D 29″ rims, Shimano MT410 15x110mm front & 12x148mm rear hubs, stainless spokes |
| Tires | Vittoria Mazza 29 x 2.4″, TNT tubeless |
| Derailleurs | Shimano Deore, 12-speed |
| Shift levers | Shimano Deore, 1×12-speed |
| Chain | KMC X12, 12-speed |
| Cassette | Shimano M6100, 12-speed, 10-51T |
| Crankset | Race Face Ride, 32T |
| BB Set | Race Face BSA |
| Pedals | N/A |
| Brakeset | Shimano MT420 4-piston hydraulic disc, 180mm front & 160mm rear RT30 rotors |
| Handlebar | Race Face Ride, 760mm x 20mm rise, 35mm diameter |
| Stem | Race Face Ride, 50mm extension, 35mm clamp diameter |
| Grips | Jamis Lock-On |
| Seat Post | KS Rage Dropper, Southpaw remote |
| Saddle | WTB Volt |
| Sizes | XS (14.5), S (15.5), M (17), L (19), XL (21) |
| Color | Storm Grey |
| Weight | 33.75 lbs |
